Codan NGT 2010 RF User Manual

02 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05978-001 - PSU 500/1000 W PA PCB
BOM Revision
Date Valid On
C132 470p 5% 500V NPO 1210
NiSn
Philips 1210CG471GBB- 46-24700-082 1
C135 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
D1 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D2 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D3 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D4 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D5 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D6 Diode, Si 200V 5A General Electric 1N5624 (365-373) 1N5624 1
D7 Diode, Schottky 40V 3A
SMC
Motorola MBRS340T3 MBRS340T3 1
D8 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D9 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D11 Diode, Schottky SOT23 Philips BAT54 BAT54 1
D101 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D102 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D103 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D104 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D105 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D106 Diode, Si 200V 5A General Electric 1N5624 (365-373) 1N5624 1
IC1 Reg, Voltage, Switching
SOIC16
National Semiconduct LM3524DM XB-03524-700 1
IC2 Driver, Half-Bridge MOSFET
600V SOIC14
IR IR21834S XF-21834-700 1
IC3 Amp, Rail to Rail I/O Low
Offset SOT23-5
National Semiconduct LMC7101AIM5 XA-07101-701 1
IC4 Comparator, Dual O/C Output
SOIC8
National Semiconduct LM393M XD-00393-700 1
IC5 Gate, NAND 2 Input Quad
SOIC14
Motorola MC74HC00AD YH-74000-700 1
IC101 Reg, Voltage, Switching
SOIC16
National Semiconduct LM3524DM XB-03524-700 1
IC102 Driver, Half-Bridge MOSFET
600V SOIC14
IR IR21834S XF-21834-700 1
IC103 Amp, Rail to Rail I/O Low
Offset SOT23-5
National Semiconduct LMC7101AIM5 XA-07101-701 1
L1 Ind, 32uH 16A SMPS Pulse PE-51507 43-81320-000 1
L2 Ind, 32uH 16A SMPS Pulse PE-51507 43-81320-000 1
L3 Ind, 145uH 3A SMPS Pulse PE-92105K 43-82145-000 1
L101 Ind, 32uH 16A SMPS Pulse PE-51507 43-81320-000 1
L102 Ind, 32uH 16A SMPS Pulse PE-51507 43-81320-000 1
P1 Header (P) 10way 2row Boxed
Fix
I-Technos HDM410S02 60-00100-003 1
P2 Header (P) 2way 1row Latch JAE IL-2P-S3EN2 60-00020-260 1
Page 3 of 7
