02 -- Production
28.09.2006
Ref Descri
tion Manufacturer Manufacturer's P/N Codan P/N Qt
08-05978-001 - PSU 500/1000 W PA PCB
BOM Revision
Date Valid On
P3 Header (P) 6way 2mm Latch
Fixed
AMP 173981-6 60-00060-350 1
P102 Header (P) 2way 1row Latch JAE IL-2P-S3EN2 60-00020-260 1
R1 100k Ohm 5% 0,1W 0805 Philips 2322 730 61104 40-51000-111 1
R2 6,8k Ohm 1% 0,1W 0805 Philips 2322 734 66802 40-36800-115 1
R3 8,2k Ohm 1% 0,1W 0805 Philips 2322 734 68202 40-38200-115 1
R4 33k Ohm 1% 0,1W 0805 Philips 2322 734 63303 40-43300-115 1
R5 27k Ohm 1% 0,1W 0805 Philips 2322 734 62703 40-42700-115 1
R6 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R7 Pot,1k Lin MG Trim SMD Bourns 3314 J-1-102 42-31004-000 1
R8 6,8k Ohm 5% 0,1W 0805 Philips 2322 730 61682 40-36800-111 1
R9 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R10 10k Ohm 1% 0,1W 0805 Philips 2322 734 61003 40-41000-115 1
R11 180 Ohm 5% 0,1W 0805 Philips 2322 730 61181 40-21800-111 1
R12 Pot,100 Lin MG Trim SMD Bourns 3314 J-1-101 42-21004-000 1
R13 3,3k Ohm 5% 0,1W 0805 Philips 2322 730 61332 40-33300-111 1
R14 1,5k Ohm 1% 0,1W 0805 Philips 2322 734 61502 40-31500-115 1
R15 68k Ohm 5% 0,1W 0805 Philips 2322 730 61683 40-46800-111 1
R16 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R17 Pot,10k Lin MG Trim SMD Bourns 3314 J-1-103 42-41004-000 1
R18 220k Ohm 5% 0,1W 0805 Philips 2322 730 61224 40-52200-111 1
R19 100k Ohm 5% 0,1W 0805 Philips 2322 730 61104 40-51000-111 1
R20 4,7k Ohm 5% 0,1W 0805 Philips 2322 730 61472 40-34700-111 1
R21 10 Ohm 5% 0,125W 1206 Philips 2322 711 61109 40-11000-101 1
R22 15 Ohm 5% 0,125W 1206 Philips 2322 711 61159 40-11500-101 1
R24 0,015 Ohm 1% 1,0W 2512 Vishay WSL2512R0150FEA 40-00015-132 1
R25 0,015 Ohm 1% 1,0W 2512 Vishay WSL2512R0150FEA 40-00015-132 1
R26 0,015 Ohm 1% 1,0W 2512 Vishay WSL2512R0150FEA 40-00015-132 1
R27 220 Ohm 1% 0,1W 0805 Philips 2322 734 62201 40-22200-115 1
R28 2,2k Ohm 1% 0,1W 0805 Philips 2322 734 62202 40-32200-115 1
