Codan NGT 2010 RF User Manual

04 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05926-001 - High Pwr PA & Ant Controller
BOM Revision
Date Valid On
J2 Socket, 15way D strght PCB
Fixed
ITT-Cannon DA-15S-OL2 60-00153-094 1
L1 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L2 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L3 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L4 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L5 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L6 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L7 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L8 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L9 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L10 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L11 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L12 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L13 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L14 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L15 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L16 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
P1 Plug, 7way Fixed NS 1507L w/round nut 60-00070-601 1
P3 Header (P) 6way 2mm Latch
Fixed
AMP 173981-6 60-00060-350 1
R1 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R2 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R3 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R4 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R5 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R6 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R7 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R8 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R9 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R10 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R11 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R12 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
Page 3 of 5
