04 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05926-001 - High Pwr PA & Ant Controller
BOM Revision
Date Valid On
R13 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R14 68 Ohm 5% 0,1W 0805 Philips 2322 730 61689 40-16800-111 1
R15 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R16 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R17 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R18 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R19 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R20 220 Ohm 5% 0,1W 0805 Philips 2322 730 61221 40-22200-111 1
R21 220 Ohm 5% 0,1W 0805 Philips 2322 730 61221 40-22200-111 1
R22 220 Ohm 5% 0,1W 0805 Philips 2322 730 61221 40-22200-111 1
R23 68 Ohm 5% 0,1W 0805 Philips 2322 730 61689 40-16800-111 1
R24 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R25 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R26 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R27 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R28 100k Ohm 5% 0,1W 0805 Philips 2322 730 61104 40-51000-111 1
R29 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R30 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R31 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R32 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R33 Not Fitted Codan **-00000-001 99-00000-001 1
R34 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R35 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R36 220 Ohm 5% 0,1W 0805 Philips 2322 730 61221 40-22200-111 1
R37 Res, Voltage Dependent Philips 2322-592-52506 41-22506-592 1
R39 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R40 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R41 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R42 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R43 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
Page 4 of 5
