Codan NGT 2010 RF User Manual

05 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-03905-002 - Dual Line Equaliser PCB
BOM Revision
Date Valid On
C208 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C209 100n 10% 63V PE Cap Philips 2222 370 11104 46-51000-521 1
C210 220p 2% 100V N750 CE
Cap
Philips 2222 680 58221 46-22200-013 1
C211 220p 10% 100V CE
Cap
Philips 2222 630 03221 46-22200-200 1
C212 33n 10% 100V PE Cap Philips 2222 370 21333 46-43300-524 1
C213 1n 10% 100V PE Cap Philips 2222 370 51102 46-31000-524 1
C214 100n 10% 63V PE Cap Philips 2222 370 11104 46-51000-521 1
C215 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C216 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C217 100p 2% 100V N150 CE
Cap
Philips 2222 680 34101 46-21000-012 1
C218 2,2u 20% 35V TA Cap AVX TAP225M035CCS 47-02203-510 1
C219 220p 10% 100V CE
Cap
Philips 2222 630 03221 46-22200-200 1
C220 220p 2% 100V N750 CE
Cap
Philips 2222 680 58221 46-22200-013 1
C221 2,2u 20% 35V TA Cap AVX TAP225M035CCS 47-02203-510 1
C222 220p 10% 100V CE
Cap
Philips 2222 630 03221 46-22200-200 1
C223 33n 10% 100V PE Cap Philips 2222 370 21333 46-43300-524 1
C224 1n 10% 100V PE Cap Philips 2222 370 51102 46-31000-524 1
C225 33n 10% 100V PE Cap Philips 2222 370 21333 46-43300-524 1
C226 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C227 100p 2% 100V N150 CE
Cap
Philips 2222 680 34101 46-21000-012 1
C228 Not Fitted Codan **-00000-001 99-00000-001 1
C229 220p 10% 100V CE
Cap
Philips 2222 630 03221 46-22200-200 1
C230 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C231 1n 2,5% 100V PP Cap Roederstein KP 1830-210/013 46-31000-702 1
C232 4,7n 2,5% 63V PP Cap Roederstein KP 1830-247/063 46-34700-702 1
C233 39p 2% 100V NPO CE
Cap
Philips 2222 680 10399 46-13900-011 1
C234 100n 20% 50V X7R CE
Cap
Vitramon VP41BY104MA 46-51000-261 1
C235 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C236 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
D1 Diode, Si small sig GP Codan 23-10005 23-10005 1
