05 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-03905-002 - Dual Line Equaliser PCB
BOM Revision
Date Valid On
D2 Diode, Si small sig GP Codan 23-10005 23-10005 1
D101 Diode, Si small sig GP Codan 23-10005 23-10005 1
D102 Diode, Si small sig GP Codan 23-10005 23-10005 1
D201 Diode, Si small sig GP Codan 23-10005 23-10005 1
D202 Diode, Si small sig GP Codan 23-10005 23-10005 1
IC1 Switch, Bilateral Quad IC National Semiconduct CD4066BCN YG-40066-000 1
IC2 Conv, D to A, 8x6 bit IIC Philips TDA8444 YN-08444-000 1
IC3 Remote 8 Bit I/O For IIC Bus
IC
Philips PCF8574P YK-08574-000 1
IC4 Not Fitted Codan **-00000-001 99-00000-001 1
IC5 Array, Transistor IC Motorola MC1413P XT-01413-000 1
IC6 Reg, Voltage +10V IC National Semiconduct LM2940T-10 XB-02940-402 1
IC101 Amp, Operational Dual LN IC Signetics NE5532N XA-05532-000 1
IC102 Amp, Low power audio IC Motorola MC34119P XA-34119-000 1
IC103 Compander, Audio IC Signetics NE571N XA-00571-000 1
IC104 Compander, Audio IC Signetics NE571N XA-00571-000 1
IC105 Amp, Operational Dual IC National Semiconduct LM358N XA-00358-100 1
IC106 Filter,Switched Cap IC National Semiconduct MF10CCN MF10CCN 1
IC107 Amp, Operational Dual IC National Semiconduct LM358N XA-00358-100 1
IC201 Not Fitted Codan **-00000-001 99-00000-001 1
IC202 Amp, Low power audio IC Motorola MC34119P XA-34119-000 1
IC203 Compander, Audio IC Signetics NE571N XA-00571-000 1
IC204 Compander, Audio IC Signetics NE571N XA-00571-000 1
IC205 Amp, Operational Dual IC National Semiconduct LM358N XA-00358-100 1
IC206 Filter,Switched Cap IC National Semiconduct MF10CCN MF10CCN 1
IC207 Amp, Operational Dual IC National Semiconduct LM358N XA-00358-100 1
P1 Connector, 64way Male 90 deg
PCB
ITT-Cannon G06D064P4BEBL 60-51100-064 1
R1 33k Ohm 20% 0,1W SIL
Com x5Res
Murata RGSD5X333M 40-84330-500 1
R2 3,9k Ohm 5% 0,33W CF
Res
Philips 2322 211 13392 40-33900-020 1
R3 1k Ohm 5% 0,33W CF
Res
Philips 2322 211 13102 40-31000-020 1
R4 1k Ohm 5% 0,33W CF
Res
Philips 2322 211 13102 40-31000-020 1
R5 3,9k Ohm 5% 0,33W CF
Res
Philips 2322 211 13392 40-33900-020 1
R6 3,3k Ohm 20% 0,1W SIL
Com x9Res
Murata RGSD9X332M 40-83330-900 1
R7 22k Ohm 5% 0,33W CF
Res
Philips 2322 211 13223 40-42200-020 1
R8 22k Ohm 5% 0,33W CF
Res
Philips 2322 211 13223 40-42200-020 1
R9 3,3k Ohm 20% 0,1W SIL
Com x5Res
Murata RGSD5X332M 40-83330-500 1
R10 22k Ohm 5% 0,33W CF
Res
Philips 2322 211 13223 40-42200-020 1
R11 22k Ohm 5% 0,33W CF
Res
Philips 2322 211 13223 40-42200-020 1
R12 Not Fitted Codan **-00000-001 99-00000-001 1
R13 2,2k Ohm 5% 0,33W CF
Res
Philips 2322 211 13222 40-32200-020 1
Page 4 of 8
