Codan NGT 2010 RF User Manual

05 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-03905-002 - Dual Line Equaliser PCB
BOM Revision
Date Valid On
R14 2,2k Ohm 5% 0,33W CF
Res
Philips 2322 211 13222 40-32200-020 1
R101 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R102 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R103 56k Ohm 5% 0,33W CF
Res
Philips 2322 211 13563 40-45600-020 1
R104 56k Ohm 5% 0,33W CF
Res
Philips 2322 211 13563 40-45600-020 1
R105 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R106 560 Ohm 5% 0,33W CF
Res
Philips 2322 211 13561 40-25600-020 1
R107 560 Ohm 5% 0,33W CF
Res
Philips 2322 211 13561 40-25600-020 1
R108 1,2k Ohm 5% 0,33W CF
Res
Philips 2322 211 13122 40-31200-020 1
R109 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R110 150k Ohm 5% 0,33W CF
Res
Philips 2322 211 13154 40-51500-020 1
R111 47k Ohm 5% 0,33W CF
Res
Philips 2322 211 13473 40-44700-020 1
R112 150k Ohm 5% 0,33W CF
Res
Philips 2322 211 13154 40-51500-020 1
R113 10k Ohm 2% 0,4W MF
Res
Philips 2322 181 54103 40-41000-500 1
R114 270k Ohm 2% 0,4W MF
Res
Philips 2322 181 54274 40-52700-500 1
R115 10k Ohm 2% 0,4W MF
Res
Philips 2322 181 54103 40-41000-500 1
R116 47k Ohm 5% 0,33W CF
Res
Philips 2322 211 13473 40-44700-020 1
R117 10k Ohm 5% 0,33W CF
Res
Philips 2322 211 13103 40-41000-020 1
R118 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R119 10k Ohm 2% 0,4W MF
Res
Philips 2322 181 54103 40-41000-500 1
R120 270k Ohm 2% 0,4W MF
Res
Philips 2322 181 54274 40-52700-500 1
R121 10k Ohm 2% 0,4W MF
Res
Philips 2322 181 54103 40-41000-500 1
R122 150k Ohm 5% 0,33W CF
Res
Philips 2322 211 13154 40-51500-020 1
R123 33k Ohm 5% 0,33W CF
Res
Philips 2322 211 13333 40-43300-020 1
R124 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R125 8,2k Ohm 5% 0,33W CF
Res
Philips 2322 211 13822 40-38200-020 1
R126 47k Ohm 5% 0,33W CF
Res
Philips 2322 211 13473 40-44700-020 1
R127 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R128 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
