Codan NGT 2010 RF User Manual

05 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-03905-002 - Dual Line Equaliser PCB
BOM Revision
Date Valid On
R129 330k Ohm 5% 0,33W CF
Res
Philips 2322 211 13334 40-53300-020 1
R130 39k Ohm 5% 0,33W CF
Res
Philips 2322 211 13393 40-43900-020 1
R131 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R132 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R133 8,2k Ohm 5% 0,33W CF
Res
Philips 2322 211 13822 40-38200-020 1
R134 56k Ohm 5% 0,33W CF
Res
Philips 2322 211 13563 40-45600-020 1
R135 Not Fitted Codan **-00000-001 99-00000-001 1
R136 1k Ohm 5% 0,33W CF
Res
Philips 2322 211 13102 40-31000-020 1
R137 330k Ohm 5% 0,33W CF
Res
Philips 2322 211 13334 40-53300-020 1
R138 120k Ohm 2% 0,4W MF
Res
Philips 2322 181 54124 40-51200-500 1
R139 130k Ohm 2% 0,4W MF
Res
Philips 2322 181 54134 40-51300-500 1
R140 130k Ohm 2% 0,4W MF
Res
Philips 2322 181 54134 40-51300-500 1
R141 Not Fitted Codan **-00000-001 99-00000-001 1
R142 Not Fitted Codan **-00000-001 99-00000-001 1
R143 4,7k Ohm 5% 0,33W CF
Res
Philips 2322 211 13472 40-34700-020 1
R144 47k Ohm 5% 0,33W CF
Res
Philips 2322 211 13473 40-44700-020 1
R145 15 Ohm 5% 0,33W CF
Res
Philips 2322 211 13159 40-11500-020 1
R146 15 Ohm 5% 0,33W CF
Res
Philips 2322 211 13159 40-11500-020 1
R201 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R202 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R203 56k Ohm 5% 0,33W CF
Res
Philips 2322 211 13563 40-45600-020 1
R204 56k Ohm 5% 0,33W CF
Res
Philips 2322 211 13563 40-45600-020 1
R205 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R206 560 Ohm 5% 0,33W CF
Res
Philips 2322 211 13561 40-25600-020 1
R207 560 Ohm 5% 0,33W CF
Res
Philips 2322 211 13561 40-25600-020 1
R208 1,2k Ohm 5% 0,33W CF
Res
Philips 2322 211 13122 40-31200-020 1
R209 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R210 150k Ohm 5% 0,33W CF
Res
Philips 2322 211 13154 40-51500-020 1
R211 47k Ohm 5% 0,33W CF
Res
Philips 2322 211 13473 40-44700-020 1
R212 150k Ohm 5% 0,33W CF
Res
Philips 2322 211 13154 40-51500-020 1
Page 6 of 8
