Installing the Rack Model ProLiant ML370 3-23
Compaq Confidential – Need to Know Required
Writer: Gilbert Saldivar Project: Compaq ProLiant ML370 Setup and Installation Guide Comments:
Part Number: 120137-002 File Name: d-ch3 Installing the Rack Model Last Saved On: 12/13/99 3:43 PM
2. Carefully align the server component rails with the rack slide rails, as
shown in the following figure.
Figure 3-16. Aligning the server component rails with the rack rails
3. Ensure that the server component rails are fully engaged into the plastic
guides and bearings on the rack rails on both sides, then slowly slide the
server into the rack. The server slides forward until the release latches
engage the rack rails.
WARNING: To reduce the risk of personal injury, be careful when pressing the
component rail release latches and sliding the component into the rack. The
slide rails can pinch your fingertips.
CAUTION: Be sure to keep the component parallel to the floor when sliding the
component rails into the slide rails. Tilting the component up or down can cause
damage to the rails.
NOTE: The first time you slide the component into the rack, you may have to apply some
pressure. With continued use, the ball bearings in the slide will move easily.
