Compaq ProLiant ML570 User Manual

Diagnostics and Troubleshooting 3-23
100 – 199, Primary Processor Test Error Codes
The 100 series of diagnostic error codes identifies failures with processor and system board
functions. Corrective action may require replacing the system boards or processor assemblies.
Table 3-3
Primary Processor Test Error Codes
Error Code Description Recommended Action
101-XX CPU test failed. Replace the processor board and retest.
103-XX DMA page registers test failed.
104-XX Interrupt controller master test
failed.
105-XX Port 61 error.
106-XX Keyboard controller self-test
failed.
Replace the processor board and retest.
107-XX CMOS RAM test failed.
108-XX CMOS interrupt test failed.
109-XX CMOS clock load data test failed.
1. Replace the battery/clock module and retest.
2. Replace the system board and retest.
110-XX Programmable timer load data test
failed.
111-XX Refresh detect test failed.
112-XX Speed test slow mode out of
range.
113-XX Protected mode test failed.
Replace the processor board and retest.
114-XX Speaker test failed. 1. Verify the speaker connection and retest.
2. Replace the speaker and retest.
3. Replace the system board and retest.
116-XX Cache test failed. Replace the system board and retest.
122-XX Multiprocessor dispatch test
failed.
123-XX Interprocessor communication test
failed.
1. Check the system configuration and retest.
2. Replace the processor board and retest.
3. Replace the system board and retest.
199-XX Installed devices test failed. 1. Check the system configuration and retest.
2. Verify cable connections and retest.
3. Check switch and/or jumper settings and retest.
4. Run the Configuration Utility and retest.
5. Replace the processor board and retest.
6. Replace the system board and retest.
