Compaq ProLiant ML570 - Diskette and CD-ROM Drive Cables; Diskette and CD-ROM

Removal and Replacement Procedures 2-31
Diskette and CD-ROM Drive Cables
2
3
1
Figure 2-22. Diskette and CD-ROM drive cable routing diagrams
Table 2-4
Diskette and CD-ROM Drive Cables
Item Description

Power cable for both diskette and CD-ROM drives

Data cable for CD-ROM drive

Data cable for diskette drive
