Removal and Replacement Procedures 2-21
SCSI Hard Drive Blanking Panel
To remove a SCSI hard drive blanking blank:
1. Perform the preparation procedures. See “Preparation Procedures” earlier in this chapter.
2. Open the front bezel doors if the unit is a tower model. See “Front Bezel Door (Tower
Model Only)” earlier in this chapter.
3. Push the sliding release button
to unlock the blanking panel.
4. Pull the hard drive blanking panel
out from the drive cage.
1
2
1
Figure 2-14. Removing the SCSI hard drive blanking panel
Reverse steps 1 through 4 to replace a SCSI hard drive blanking panel.
