2-58 Compaq ProLiant ML570 Maintenance and Service Guide
Replacement Battery
To remove the CMOS battery and to install the replacement battery:
CAUTION: Do not dispose of batteries, battery packs, and accumulators with the
general household waste. To forward them to recycling or proper disposal, use the
public collection system or return them to either Compaq or your Compaq
authorized service provider.
1. Perform the preparation procedures. See “Preparation Procedures” earlier in this chapter.
2. Remove the access panel. See “Access Panel (Tower and Rack)” earlier in this chapter.
3. Remove the peripheral board. See “Peripheral Board (Non-Hot-Pluggable)” earlier in
this chapter.
WARNING: Disconnect all power cords to completely remove power from the system before
removing the peripheral board.
4. Remove the lithium battery from the peripheral board as shown in Figure 2-48.
Figure 2-48. Removing the lithium battery from the peripheral board
