Removal and Replacement Procedures 2-53
Power Supply Blanking Panel
CAUTION: When the power supply is not being replaced, cover the opening with a
power supply blanking panel to maintain proper airflow.
To remove a power supply blanking panel:
1. Perform the preparation procedures. See “Preparation Procedures” earlier in this chapter.
2. Remove the two T-15 screws
securing the power supply blanking panel to the chassis.
3. Pull the power supply blanking panel
away from the chassis.
1
2
Figure 2-43. Removing the power supply blanking panel
Reverse steps 1 through 3 to replace a power supply blanking panel.
