4-2 Compaq ProLiant ML570 Server
Connectors
This section contains information about connectors located on the ProLiant ML570 server.
Rear Panel Connectors
Figure 4-1 shows the rear panel connectors for the ProLiant ML570 server. Table 4-1 shows the
corresponding connector descriptions.
1
3
2
Figure 4-1. Rear panel connectors
Table 4-1
Rear Panel Connectors
Item Connector
➊
Peripheral board rear connectors (See “Peripheral Board Connectors” later in
this chapter.)
➋
Compaq NC3123 Fast Ethernet NIC PCI 10/100 Wake on LAN
(WOL) Controller (RJ-45)
➌
AC power connectors
