Illustrated Parts Catalog 1-5
System Components Spare Parts List
Table 1-2
System Components Spare Parts List
Item Description Spare Part Number
8 System chassis (same as item 1, Figure 1-1)
a) Rack 174570-001
b) Tower * 174569-001
9 Hot-plug system fan (2) 122225-001
10 Hot-plug hard drive fan (3) 161657-001
11 Miscellaneous plastics kit 178195-001
a) Hard drive fan air baffle
b) CPU fan air baffle (shown in Figure 1-3)
c) Expansion board slot release lever (port-colored and beach gray) *
d) PCI retainers *
e) Option board retainers *
f) Media locking latch (green) *
12 System fan basket (2) 161658-001
13 Miscellaneous hardware kit 159321-001
a) System fan basket adapter with cable (left)
b) System fan basket adapter with cable (right)
c) Removable media bay blanking panel
14 Power supply, 450 watts, hot-plug (2) 157793-001
15 Power On/Standby switch with LED indicators 161659-001
Boards
16 Power supply backplane board, hot-plug 159314-001
Mass Storage Devices
17 CD-ROM drive 179963-001
18 1.44-MB diskette drive 123958-001
* Not shown
