2-30 Compaq ProLiant ML570 Maintenance and Service Guide
Cable Routing Diagrams
CAUTION: When routing cables, always ensure that the cables are not in a position in which
they can be pinched or crimped.
System Board Power Cables
21
Figure 2-21. System board power cables routing diagram
Table 2-3
System Board Power Cables Routing
Item Description
Power cable
Power cable
