Removal and Replacement Procedures 2-9
Front Bezel Door (Tower Model Only)
WARNING: To reduce the risk of personal injury from hot surfaces, allow the internal system
components to cool before handling the components.
To remove the front bezel door:
1. Perform the preparation procedures. See “Preparation Procedures” earlier in this chapter.
2. Swing open the front bezel door approximately 45 degrees.
3. Lift the front bezel door  up, then pull it away from the chassis hinges  .
2
1
Figure 2-2. Removing the front bezel door (tower model only)
Reverse steps 1 through 3 to replace the front bezel door.
