Processors, Terminator Boards, and Processor Cage
Processors
The ProLiant ML570 server supports up to four processors. Figure 2-37 shows the location of
the processors. Table 2-8 identifies processor locations on the ProLiant ML570 server.
Top View
of
System Board
1 2 3 4
Figure 2-37. Processor locations
Table 2-8
Processor Locations
Item Description

Processor 1

Processor 2

Processor 3

Processor 4
