4-4 Compaq ProLiant ML570 Server
Peripheral Board Connectors
Figure 4-3 shows the ProLiant ML570 server peripheral board connectors. Table 4-3 identifies
the corresponding connectors.
1 2 3
5
4
6
8 79
10
11
Figure 4-3. Peripheral board connectors
Table 4-3
Peripheral Board Connectors
Item Description

SCSI port 1 connector

SCSI port 2 connector

Parallel port connector

VHDC SCSI connector

NMI switch access (debugging only)

Video connector

Mouse connector

Keyboard connector

Serial connector

Battery connector

Integrated Smart Array Controller connector
