Connectors, Switches, and LED Status Indicators 4-19
CD-ROM Drive LED Indicator
The CD-ROM drive LED indicator  is located on the front of the CD-ROM drive near the
volume wheel. The LED indicator illuminates green whenever the CD-ROM drive is in
operation. Figure 4-15 shows the CD-ROM drive LED indicator for the ProLiant ML570 server.
1
Figure 4-15. CD-ROM drive LED indicator
Diskette Drive LED Indicator
Figure 4-16 shows the location of the diskette drive LED indicator  . The LED indicator
illuminates green when the diskette drive is in operation. Table 4-16 shows the diskette drive
LED indicator on the ProLiant ML570 server.
1
Figure 4-16. Diskette drive LED indicator
