Compaq ProLiant ML570 User Manual

Illustrated Parts Catalog 1-7
Electronics Drawer System Components Spare Parts List
Table 1-3
Electronics Drawer System Components Spare Parts List
Item Description Spare Part Number
Boards
19 System board kit 168063-001
a) System board
b) System board tray (electronics drawer)
c) Processor cage assembly
d) Insulator basket
e) PCI Hot Plug Switchboard with cable (see item 25) *
f) Screws, 6-32 x 0.312 inch (20) *
g) Screws, (T-15) 6-19 x 0.375 inch (3) *
20 Memory board, 16-DIMM 168064-001
21 Processor with green-colored heatsink
a) 700-MHz with 1-MB cache 175292-001
b) 700-MHz with 2-MB cache * 175293-001
c) 900-MHz with 2-MB cache * 188594-001
22 Terminator board 329271-001
23 NC3123 Fast Ethernet NIC PCI 10/100 Wake on LAN (WOL) 174831-001
24 Peripheral board 101951-001
25 PCI Hot Plug LED switchboard 168066-001
Memory
26 128-MB DIMM (100-MHz SDRAM, 64-Megabit, CL-2) 146488-001
27 256-MB DIMM (100-MHz SDRAM, 128-Megabit, CL-2) * 146489-001
28 256-MB DIMM (100-MHz SDRAM, 64-Megabit, CL-2) * 170514-001
29 512-MB DIMM (100-MHz SDRAM, 128 Megabit, CL-2) * 170515-001
30 512-MB DIMM (100-MHz SDRAM, 256-Megabit, CL-2) * 170515-001
31 1-GB DIMM (100-MHz SDRAM, 256-Megabit, CL-2) * 170518-001
* Not shown
continued
