Dual Inline Memory Module Combinations
Table 2-6
Dual Inline Memory Module (DIMM) Combinations
Total Memory Socket 1 Socket 2 Socket 3 Socket 4 Socket 5 Socket 6 Socket 7 Socket 8
256 MB 64 MB 64 MB 64 MB 64 MB
768 MB 64 MB 64 MB 64 MB 64 MB 128 MB 128 MB 128 MB 128 MB
512 MB 128 MB 128 MB 128 MB 128 MB
1 GB 256 MB 256 MB 256 MB 256 MB
2 GB 256 MB 256 MB 256 MB 256 MB 256 MB 256 MB 256 MB 256 MB
2 GB 512 MB 512 MB 512 MB 512 MB
3 GB 256 MB 256 MB 512 MB 512 MB 256 MB 256 MB 512 MB 512 MB
4 GB 512 MB 512 MB 512 MB 512 MB 512 MB 512 MB 512 MB 512 MB
Note: These are examples only. Because the board has 16 sockets, more DIMM combinations can be added as long as the DIMMs
are installed in sets of four modules per bank. DIMMs must be identical in each bank.
