2-52 Compaq ProLiant ML570 Maintenance and Service Guide
To remove a hot-plug power supply:
1. Perform the preparation procedures. See “Preparation Procedures” earlier in this chapter.
2. Press the thumb latch
in the middle of the power supply handle to release the handle.
NOTE: If a security screw is present on the power supply, remove the screw before removing the
power supply.
3. Pull the handle
outward.
4. Slide the power supply
from the chassis.
2
3
1
Figure 2-42. Removing a hot-plug power supply
Reverse steps 1 through 4 to replace a hot-plug power supply.
CAUTION: When the power supply is not being replaced, cover the opening with a
power supply blanking panel to maintain proper airflow.
