Compaq ProLiant ML570 User Manual

4-16 Compaq ProLiant ML570 Server
Table 4-12
PCI Hot Plug LED Indicators
LED Condition Power Status OK to Open Slot Status
 Green
 Amber
On
Off
No Power is currently applied to the slot. Do NOT open the
slot release lever. The slot is functioning normally.
 Green
 Amber
On
On
No Power is currently applied to this slot but the slot needs
ATTENTION for possible problem with the slot, board, or
driver. Do NOT open the slot release lever. Follow these
steps:
1. Through the PCI Hot Plug application, turn power
Off to the slot (the green LED turns Off).
2. Open the slot release lever (the amber LED turns
Off).
3. Remove or replace the board.
4. Connect the cables to the PCI board.
5. Close the slot release lever.
6. Return power to the slot through the PCI Hot Plug
application (the green LED turns On).
 Green
 Amber
Flashing
On
No Power slot is being turned Off or On, which may take
several minutes. There may be a problem with the slot,
the PCI board, or the driver. Do NOT open the slot
release lever until the green LED is completely Off.
 Green
 Amber
Off
On
No Power to this slot is turned Off but this slot needs
ATTENTION. There may be a problem with the slot,
board, or driver.
1. Open the slot release lever (the amber LED
turns Off).
2. Remove or replace the board.
3. Connect the cables to the PCI board.
4. Close the slot release lever.
5. Return power to the slot through the PCI Hot Plug
application (the green LED turns On.)
 Green
 Amber
Off
Off
Yes The power to the slot is Off. If you need to replace the
board in this slot, follow these steps:
1. Open the slot release lever.
2. Remove or replace the board.
3. Connect the cables to the PCI board.
4. Close the slot release lever.
5. Return power to the slot through the PCI Hot Plug
application (the green LED turns On.)
