3.29. DynamicRoutingRule
Description
A Dynamic Routing Policy rule creates a filter to catch statically configured or OSPF learned
routes. The matched routes can be controlled by the action rules to be either exported to OSPF
processes or to be added to one or more routing tables.
Properties
Index The index of the object, starting at 1. (Identifier)
Name Specifies a symbolic name for the rule. (Optional)
From OSPF or Routing table. (Default: OSPF)
OSPFProcess Specifies from which OSPF process the route
should be imported from into either a routing
table or another OSPF process.
RoutingTable Specifies from which routing table a route should
be imported into the OSPF AS or copied into
another routing table.
DestinationInterface The interface that the policy has to match.
(Optional)
DestinationNetworkExactly Specifies if the route needs to match a specific
network exactly. (Optional)
DestinationNetworkIn Specifies if the route just needs to be within a
specific network. (Optional)
NextHop The next hop (router) on the route that this policy
has to match. (Optional)
MetricRange Specifies an interval that the metric of the routes
needs to be within. (Optional)
RouterID Specifies if the policy should filter on router ID.
(Optional)
OSPFRouteType Specifies if the policy should filter on OSPF router
type. (Optional)
OSPFTagRange Specifies an interval that the tag of the routers
need to be within. (Optional)
LogEnabled Enable logging. (Default: Yes)
LogSeverity Specifies with what severity log events will be sent
to the specified log receivers. (Default: Default)
Comments Text describing the current object. (Optional)
Note
If no Index is specified when creating an instance of this type, the object will be placed
Chapter 3: Configuration Reference
158
