xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
241
The fields that can be configured are described below:
Parameter Description
Group Address
Enter the multicast group network address for this static RP.
RP Address
Enter the IPv6 address to this static RP.
Override Dynamic
Tick the check box so that the static RP will override any dynamically learned RP.
Click the Add button to add a new entry based on the information entered.
Click the Delete button to remove the specific entry.
PIM for IPv6 Neighbor Table
This window is used to display the current PIM for IPv6 neighbor router table.
To view the following window, click L3 Features > IP Multicast Routing Protocol > PIM > PIM for IPv6 > PIM for
IPv6 Neighbor Table, as shown below:
Figure 5-124 PIM for IPv6 Neighbor Table window
The fields that can be configured are described below:
Parameter Description
Interface Name
Enter the name of the IP interface for which you want to display the current PIM for
IPv6 neighbor routing table.
Click the Find button to find the interface entered.
Click the View All button to view all PIM for IPv6 neighbors on this switch.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
PIM for IPv6 Multicast Route Table
This window is used to display the current PIM for IPv6 multicast route table.
To view the following window, click L3 Features > IP Multicast Routing Protocol > PIM > PIM for IPv6 > PIM for
IPv6 Multicast Route Table, as shown below:
Figure 5-125 PIM for IPv6 Multicast Route Table window
