xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
242
The fields that can be configured are described below:
Parameter Description
Enter the IPv6 multicast group address.
Click the Find button to find the group address entered.
Click the View All button to view all PIM for IPv6 multicast routes on this switch.
Click the View Detail link to view more information regarding the specific entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Click the View Detail link to see the following window.
Figure 5-126 PIM for IPv6 Multicast Route Table - View Detail window
The fields that can be configured are described below:
Parameter Description
Enter the IPv6 source address.
Click the <<Back button to return to the previous window.
Click the Find button to find the source address entered.
Click the View Detail link to view more information regarding the specific entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Click the View Detail link of the (S, G) entry to see the following window.
Figure 5-127 PIM for IPv6 Multicast Route Table - View Detail window
