User Interface
174
DX8210 Barcode Scanner
Field of View Stop Angle (DS8110)
Enter the field of view (FOV) stop angle in the field provided. This will adjust the
start FOV angle to that specified.
Barcode Reconstruction
Select the check box to enable Advanced Code Reconstruction (ACR™ 4) when
reading the code. If not checked, standard linear reading mode will be used. Enable
Stacked Codes
Select the check box to improve code reconstruction when two or more codes (of
the same or different symbologies) are stacked one on top of the other with little or
no space between them.
Configure ETH-2 for Dedicated Setup/Aux
In a master/slave system (scanner as master, not an SC5000), this option is
available for slave scanners. Select the check box to enable.
This option applies to the last slave scanner in the daisy-chain system, allowing the
open Ethernet port to work as a dedicated setup port.
In practice, you can always communicate using this port, but selecting the
checkbox turns off all of the other EBC traffic on that port.
Advanced Reading Settings
Use Advanced Analysis (ACRS)
Select the checkbox to enable advanced decoding options that may help some
applications. However, they can cause increased processing time.
Overflow Start Ratio
Enter the minimum expected width of the barcode starting quiet zone, expressed
in number of modules from 1 to 50.
Overflow Stop Ratio
Enter the minimum expected width of the barcode stopping quiet zone, expressed
in number of modules from 1 to 50.
This option is only available for the DS8110 scanner.
This item may increase data processing time. The delay may affect the scanners
ability to provide a good read in time for data transmission.
This option must only be applied to the last slave scanner in the EBC network. Applying
this option to the other slaves will disrupt the EBC network.
Advanced Reading Settings are intended for special cases only, and must only be
applied with the guidance of Datalogic Support.
Use the DS8110 and DX8210 Digitizer Settings to increase scan element throughput
and provide support for a white belt and wooden box filter.
