Single Label
Reference Manual 79
Single Label
When Single Label has been selected from the Code Combination drop-down
list, the Barcode Configuration window reveals related input fields.
1. Enter the appropriate information in the form as described below:
Code Combination - Single Label has been selected.
No Read Message
Select Disable No Read Message, Global No Read Message, or Local No Read(s)
Message from the drop-down list. The No Read condition occurs whenever a code
cannot be read or decoded.
Disable No Read Message: The No Read Message is not transmitted.
Global No Read Message: The No Read String
will be sent if the scanner is
unable to decode one or more barcodes in the reading phase.
The Global No Read String is sent if none of the bar codes in the bar codes
settings table are read. When any one of the bar cods in the table are read,
then the local no read is used; if no bar codes are read then the Global No
Read Message is transmitted if the options is selected.
Local No Read(s) Message: Do not use this option when working in Single
Label mode. The Local No Read Message uses a not read message for each
code selected. With the Standard Multi Label and Code Collection option the
Local No Read messaged is defined in the barcode settings table located
under the individual bar code option the local no read message is defined on
the bar code configuration page. There is no local no read message in the
single label option.
Use 'Global No Read String' when No Codes Read
Select the check box to allow the Global No Read String to be used if no codes at all
are read. This option is not available when Global No Read Message is selected
from the No Read Message drop-down list.
Global No Read String (max. 128 chars)
Click to activate the Text Entry Tool and create a string to be displayed when
Global No Read Message is selected from the No Read Message drop-down list.
Multi Filters
Select the check box to display the Multi-Filter Settings options.
Multi-Filter Settings
Contained Filter
Select the check box to reveal the Max Number of Different Characters field.
When checked, this filter attempts to eliminate false multiple reads by determining
if a short code read is "contained in" (is a sub-string of), another longer code read.
These filter options are provided to eliminate false multiple reads.
