Tachometer Wiring to CBX510

Reference Manual 33

Photoelectric Sensor (PNP)

Tachometer Wiring to CBX510

DX8210 applications over a conveyor belt use an accessory tachometer and

mounting kit. The following diagrams illustrate standard recommended wiring of

an encoder to the CBX510 terminal block.
