Electrical Installation
22
DS8110 Barcode Scanner
Connecting a DS8110 Scanner
To install a DS8110 barcode scanner, follow this sequence:
• Complete mechanical installation
(See Chapter
.)
• Complete electrical installation
(See wiring illustrations provided in this
chapter.)
• Observe all electrical safety requirements outlined in this chapter.
• Ground the mounting structure to protective earth (PE) ground.
• If used, wire the photoelectric sensor (or other trigger) to the CBX510 con-
nection box/SC5000.
• Wire the tachometer to the CBX510 connection box/SC5000 (if used).
• Wire serial ports to the CBX510 connection box/SC5000 if needed.
• Connect the M12 end of the Ethernet cable to the scanner’s HOST port and
ne
two
rk switch as required by your application.
• Connect the scanner to its power supply.
• Connect the power supply t
o
the power source.
• Setup / check scanner operations
(See Chapter
.)
Everything should be MECHANICALLY INSTALLED before performing any ELECTRICAL
INSTALLATION. See Chapter for mechanical installation details.
Most DS8110
applications are shipped with the CBX connection box and all the neces-
sary cabling required to electrically install the system. If your system requires custom-
length cables or other special wiring, documentation specific to these requirements has
been provided in your shipment. This special documentation supersedes any contradic-
tory content in this manual.
To reduce the possibility of damage to the unit, check all cabling between the scanner
and other devices for accuracy.
