CBX Industrial Connection Box
Reference Manual 11
CBX Industrial Connection Box
CBX Series are industrial connection boxes that can be used to connect the bar-
code scanners to an encoder/tachometer, photoelectric sensor, serial devices,
re
lays, or other peripherals. The CBX510 includes a BM100 backup module,
which allows easy parameter restore and backup operations. The backup module
also provides an easy way to upload existing parameters to a replacement bar-
code scanner when necessary. See section for wiring options.
Industrial Connection Box
CBX510 Connection Box CBX510 for DS8110 and DX8210 93A301087
CBX510 Connection Box C B X 5 1 0 A L L I N O N E + B A 2 0 0 93A301091
Scanner operation requires a CBX510 connection box or SC5000 controller.
