Device Settings | Options
Reference Manual 173
Device Settings | Options
Use the Options window to configure the scanner LEDs and X-Press Interface.
To view the Options settings:
1. In the menu under Modify Settings, navigate t
o Device Settings | Device
Name (if applicable) | Options. The Options window opens.
2. Enter the appropriate information in the form as described below:
Field of View Start Angle (DS8110)
Enter the field of view (FOV) start angle in the field provided. This will adjust the
start FOV angle to that specified.
In the example below, the original Start Angle of 30° is reduced to 25° degrees
when that value is entered.
If more than one device is included in the scanning system, the device name will be
listed in the menu tree after the Device Settings level.
Options will vary depending on which device is being represented.
This option is only available for the DS8110 scanner.
