260
DS8110 Barcode Scanner
Chapter 8
Technical Features
This chapter provides detailed specifications for the DS8110 Barcode Scanning
Systems. It provides specific information on:
•Electrical Features
•Optical Features
• Reading Features
• Physical Features
• Environmental Features
• X-PRESS Interface
• Software Features
Technical Specifications
ELECTRICAL FEATURES
Power
Supply Voltage 20-30VDC
Consumption
0.72 to 0.5 A Max. (1.3 A ma
x peak at motor start-up)
20 W typical
Distributable Current
(through I/O connector)
0.6 A Max.
Communication Interfaces
Main RS232
Main RS422 full-duplex
1200 to 115200 bit/s
1200 to 115200 bit/s
Auxiliary RS232 1200 to 115200 bit/s
Ethernet (x2) TCP/IP 100 Mbit/s
EBC Internal Network 100 Mbit/s
Fieldbus
Embedded: EtherNet/IP
Supported through CBX510 connection box or SC5000 models: PROF-
INET-IO, PROFIBUS-DP
Inputs
3 opto-coupled and polarity insensitive NPN/PNP digital inputs (5-30
Vdc)
Outputs 2 opto-coupled software programmable N
PN digital outputs
