Technical Specifications
Reference Manual 261
OPTICAL FEATURES
Wavelength 630 to 680 nm
Safety Class Class 2 - EN60825-1; Class II – CDRH
Light Source Visible laser diode
Laser Control Security system to turn laser off
in case of motor slow down
Optic Architecture / Tech-
nology
ASTRA™
Focusing System Fixed focus position
READING FEATURES
Scan Rate Typ.:1000 scans/s/ Max.
Maximum Resolution Min:0.25mm (10mils)/Max: 1.0mm (40mils)
Max. Reading Distance See section Reading Diagrams
Max. Reading Width See section Reading Diagrams
Max. Depth of Field See section Reading Diagrams
Scan Pattern Type Linear
PHYSICAL FEATURES
Dimensions 216 x 96 x 127 mm [8.5 x 3.8 x 5.0 in]
Weight 2.0 kg (4.4 lb)
Enclosure Aluminum Alloy
Connections I/O, POWER, ETH1, ETH2; Other connections through CBX510
ENVIRONMENTAL FEATURES
Temperature
Operating: 0 to 50 °C (32 to 122 °F)
Storage: -20 to 70 °C (-4 to 158 °F)
Relative Humidity 10-90% non-condensing
Ambient light immunity >30,000 LUX
Vibration Resistance
SINE vibration as per EN60068-2-6
2-10Hz : 14mm / 13-55Hz : 1.5mm / 70-500Hz : 2g
2h per axis / 3 axes
Shock Resistance
As per EN60068-2-27, 30g / 11ms / 3 tim
es up and 3 times down on each
axis / 3 axes
Protection Class IP65
X-PRESS INTERFACE
LED Indicators Ready, Good, Trigger, Com, Status
Keypad
HMI Keypad for alternative configuration and test mode and Restore Fac-
tory Default
