User Interface
178
DX8210 Barcode Scanner
Near
GREEN indicates the barcode has been scanned by the near-focus laser.
Far
GREEN indicates the barcode has been scanned by the far-focus laser.
Messages
Message Field
Displays message data being returned by the scanner for each barcode scanned.
Read Rate
Package Count
Displays the number of packages detected since the last reset.
Good Read (%)
Displays the number of good barcode reads since the last reset.
Multiple (%)
Displays the number of multiple barcodes detected since the last reset.
Partial (%)
Displays the number of partially read barcodes since the last reset.
No Read (%)
Displays the number of no reads (no barcode read on package) since the last reset.
Reset
Click to reset the above counters.
Message Monitor
Message Monitor Field
Select the option button beside Main, Aux, Socket 1, Socket 2, Socket 3, Socket 4,
Socket 5, Socket 6, or Fieldbus to display messages for that host port.
Select the option button beside None to stop displaying messages.
Connect/ Disconnect
Click Disconnect to stop (freeze) the Monitor window, or click Connect to start the
Monitor window.
