V1108, 10.3
• Parameters
Bend no . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..BN =
Selection of a bend of the active program.
Repetition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..CY
Selection of one of the repeated steps of one bend. Useful if a bend has a repetition
value larger than 1. This parameter becomes visible when the function key 'select rept.
no' is pressed.
Corr.
α1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..Cα=
Corr.
α2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..Cα=
Corrections on angle values (C
α) in this bending.
Angle corrections can be programmed for both sides of the machine, Y1 and Y2. When
correction
α1 is entered for one side, this value is automatically copied to the α2
correction for the other side. The correction for the other side can then be changed.
When both angle corrections have been entered, the resulting corrections for Y-axis and
parallelism are calculated. The corrections will be saved in the active bending program.
The angle correction should be entered as following examples indicate:
1) Programmed value of 90 degrees.
Measured value of 92 degrees.
Then it is required to program Corr.
α with -2.
2) Programmed value of 90 degrees.
Measured value of 88 degrees.
Then it is required to program Corr.
α with +2.
In case the angle correction database has been switched on, the control checks whether a
correction exists for this type of bend in the database. The result of this check is prompted in
the entry field:
view
bends
Switch to a table view in which all bends are shown.
graphical
vis.
Switch to graphical visualisation of the program.
zoomed
values
Switch to view with axes values.
axis state Switch to view with state of the available axes. Available
for service purposes.
view notes Open a window with notes about the current product.
Function keys:
