V1108, 1.1
1. Operation overview and general introduction
1.1. The control unit
The control looks as follows:
1.a
The precise outfit of your control may vary.
Operation of the control is done with the various keys on the front panel. A description of all
keys and their functions is given in the next section.
Beside the front panel keys, a built-in touch pad or external USB mouse can be used as a
pointing device to select menu items, parameters or function keys. It depends on your
configuration whether such a device is available. In this manual the phrase ‘mouse’ is used to
describe any of these possible pointing devices.
screen
function keys
wheel
arrows
mode keys
start/stop
num. keys
em. stop
button
