V1108, 4.15
Move bend
In the table overview of the bend sequence, it is possible to change the order of bends simply
by moving a bend to another place. Use the arrow keys to move the cursor to the bend that
must be replaced. Then press the button ‘mark bend’ and the bend number is highlighted.
Now use the arrow key to move to the right place in the sequence. When the correct bend
number is highlighted, press ‘move bend’. The bend will be inserted on the current place.
Swap bends
With this command, two bends can change place in the bend sequence. Move the cursor to
one of the required bends and press the ‘mark bend’ button. Then move the cursor to the
bend with which it must be swapped and press ‘swap bends’. If for any reason the action must
be cancelled, press the function key ‘abort mark’ during the procedure.
A bend is no longer marked when the mark is aborted, when an action is finished or when this
menu is left.
4.3. Special edit function
When a new program has been made and several tests are required, the operator can switch
from "edit"-mode directly to the "auto"-mode and vice versa by pressing the particular mode
buttons.
When in "data editing" a specific bending is selected, the operator can now select the
"automatic mode" or "step by step mode".
In case one wants to edit the program, the edit mode can be selected directly with the
programming key. In this way many key operations are saved in order to make program
changes quickly.
Note:
This special edit function can not be used with connected programs.
4.4. Remarks
After changing program data in the menu ‘Data edit’ the control will not automatically
calculate:
Function keys:
move bend Move a bend to another place in the program. See also
description below.
swap
bends
Let two bends swap places. See also description below.
abort mark Remove the mark from the currently marked bend.
