V1108, 4.6
The bend number, product ID and product description are displayed in the top row on the
screen.
• Parameter explanation
Punch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .UP
The name (ID) of the applied punch.
Die . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .UN
The name (ID) of the applied die.
Program the desired tool numbers or press the key to select a tool from the list. Use the
function key ‘Show library’ to check the available tools.
Function keys:
previous
page
Select the previous page with parameters of this bend.
next page Select the next page with parameters of this bend.
previous
bend
select previous bend
next bend select next bend
show
library
Open a window with an overview of the tool library. From
here, a tool can be selected. Only available if the
program cursor is positioned on a tool.
alphanum. Select an alphanumeric character after typing. The
possible characters are displayed on the frontpanel key.
Only possible at relevant parameters.
turn punch
/
turn die
Turn around the applied tool (back to front). Only
available if the cursor is placed on a tool parameter.
all bends Open a new window, in which all bends are shown in a
table.
END To end the data prep./edit mode and return to the main
menu.
