V1108, 3.15
3.4.2. Unbend product
In order to generate a CNC-program the bend sequence must be known. There are two ways
to achieve this:
• Press the function key ‘compute’ (S5). The control will automatically compute the
quickest possible bend sequence for this product.
• Press the function key ‘unbend’ (S1) repeatedly, until the product is completely unbent.
When the product is completely unbent, press the function key ‘store’ (S5) to generate and
store the CNC-program.
shift gauge
/ shift
product
Shift the product manually (if product is bent) or shift the
gauge manually (if product is unbent).
manual
selection
Manual selection of a bend line. Additional possibility to
determine the bend sequence.
compute
/
Compute a valid bend sequence.
store Compute a numeric program and save it on disc. The
resulting CNC program contains all necessary axis
positions and tool numbers.
This command can only be executed when a complete
bend sequence has been determined.
view Button to select a possible viewing mode:
- 2D
- 3D
show Toggle between some possible ways of displaying the
product/tool configuration:
- product
- product/tools
- all
show
bendseq
Show bend sequence. To show a mosaic screen with a
step-by-step graphical overview of the bend sequence.
END Return to the drawing.
Function keys:
