Delem DA-65W - Connecting CNC Programs

V1108, 4.4
Angle selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .mα
Selection of the programming mode for the Y-axis.
0 = absolute: program the absolute Y-axis position for a bend.
1 =
α: program the angle to bend. The required Y-axis position is computed.
Depending on this parameter, either the parameter 'angle' or the parameter 'bend
position' will appear in a bend step.
Press the key to select the required setting.
Thickness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TH
Thickness of the sheet.
Material . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .M
Selection of one of the programmed materials, which are used to calculate the bending
depths. The control contains 4 pre-programmed materials. In total, 99 materials can be
programmed on the control. See the chapter about programming constants how to
program materials.
Press the key to select the required setting.
Blank length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .L
The required length of the original sheet from which the product is bent. If the program
has been processed from a 2D drawing, this value has been calculated.
Connect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .CN
The parameter "connect" is to have a possibility to connect certain programs to one
another. This option can be used to produce 3-dimensional products out of two
programs.
Use adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .UA
Program whether or not a tool adapter is used for this product. The use of an adapter
affects the calculated Y-axis position for all bends. Whether an adapter can be
programmed depends on the parameter ‘enable adapters’ in the programming
constants.
Press the key to select the required setting.
• Connecting CNC programs
With the parameter Connect it is possible to create a 3-dimensional product. The control
automatically executes the bend sequences in the different directions in succession. You
program the control as follows:
1 Create the product in one direction.
E-MODULE
(N/mm²)
TENSILE
STRENGTH
(N/mm²)
1 = Steel
2 = Aluminium
3 = Zinc
4 = Stainless steel
210.000
70.000
94.000
210.000
400
200
200
700
