Note:
When a bend in the bend sequence is adjusted manually with one of the available functions, it
must be confirmed by pressing ‘unbend’. Otherwise, it will not be stored in the sequence.
3.4.5. Move fingers
The control automatically computes at each bend the X-axes, R-axes and Z-axes positions.
It takes into account the values of the option assignments and searches for a solution without
collision of the fingers with the product. In order to be able to choose alternative positions, you
can move the fingers manually.
When the product is unbent, press ‘shift gauge’ (S3). A pop-up window displays the
backgauge fingers with one finger highlighted.
shift left Shift product to the left within the same toolset. The step
size is displayed at the command line prompt and can be
changed.
shift right Shift product to the right within the same toolset. The
step size is displayed at the command line prompt and
can be changed.
show Select a possible view of the simulation:
- product
- product/tools
- all
no change Leave the current screen without saving changes. This
can also be done by pressing END.
accept Save the changes and leave the current screen.
Function keys:
