V1108, 3.12
Backstop against sharp angle allowed. . . . . . . . . . . . . . . . . . . . . . . .SA
Specify if backstop may be placed against an angle smaller than 90°.
0 if not allowed
1 if allowed
Press the key to select the required setting.
3.o
Backstop-die, intermediate bend . . . . . . . . . . . . . . . . . . . . . . . . . . . .IB
Set to allow if there may be a bend between the die and backstop.
Selection possibilities:
0 = permitted
1 = if unavoidable permitted: if it results that no solutions are to be found, than it is
permitted
2 = prohibited: never allowed.
Press the key to select the required setting.
3.p
Edge tolerance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ET
In case backstop is against flat sheet an angle tolerance is allowed (deviation from
horizontal).
To be programmed in degrees of tolerance (0 - 90° input).
3.q
