c. Repeat the procedure for the remaining two nuts.
d. Return to the first nut and loosen it completely.
NOTE: Ensure that the anti-tilt wires on the PHM are in locked position when loosening the captive nuts.
3.
Set all the anti-tilt wires to unlocked position (inward position).
Figure 82. Removing the processor heat sink module
4. Lift the PHM from the system and set the PHM aside with the processor side facing up.
112
Installing and removing system components
