Dell PowerEdge XR8620t

Figure 65. Removing the M.2 SSD module
Next steps
Replace the M.2 SSD module.
Installing the M.2 SSD module on the BOSS-N1 card
Prerequisites
1. Follow the safety guidelines listed in Safety instructions.
2. Follow the procedure listed in Before working inside your system.
Steps
1. Align the M.2 NVMe module at an angle with the M.2 direct riser connector on BOSS-N1 card.
2. Insert the M.2 NVMe module firmly until it is fully seated in the M.2 direct riser connector.
3. Replace the screw and tighten it to secure the M.2 SSD module on the BOSS-N1 card.
NOTE:
The BOSS-N1 card can accommodate two M.2 SSD modules, repeat the same procedure to install the second
M.2 SSD module.
Installing and removing system components 97
