Dell PowerEdge XR8620t User Manual

Dell PowerEdge XR8620t system
configurations and features
The PowerEdge XR8620t system is a 2U half-width, single processor server sled that supports:
● One 4th Generation Intel Xeon Scalable processor with up to 32 cores
● Eight DDR5 DIMM slots
● PCI Express® (PCIe) 5.0 enabled expansion slots
● 2 x M.2 2280 or 22110 direct connect NVMe drives on ROR-N1 module (RAID) or dual M.2 NVMe direct riser module
(non-RAID) or BOSS-N1 with 2 x 2280 NVMe SSDs.
CAUTION: Do not install GPUs, network cards, or other PCIe devices on your system that are not validated
and tested by Dell. Damage caused by unauthorized and invalidated hardware installation will null and void the
system warranty.
Topics:
• System configurations - front view for PowerEdge XR8620t
• System configurations - rear view for PowerEdge XR8620t
• System configurations - inside view for PowerEdge XR8620t
• Locating the Express Service Code and Service Tag
• System information label
System configurations - front view for PowerEdge
XR8620t
Figure 1. Front view for PowerEdge XR8620t
Table 1.
Front view of the sled
Item Ports, panels, or slots Icon Description
1 PCIe expansion card slot 1 N/A Enables you to access the
PCIe expansion card installed
on Riser 1 in the system.
2
8 Dell PowerEdge XR8620t system configurations and features
