Figure 76. Riser 1 heater manager (Slot 2)
Table 71. Riser 1 heater manager (Slot 2)
Order From To
1 PCIe from Riser 1 Slot 2 HM heater (2U_PDB_HEATER10)
2 PCIe from Riser 1 Slot 2 HM sensor (MB_SENSOR8)
System memory
System memory guidelines
The PowerEdge XR8620t system supports DDR5 registered DIMMs (RDIMMs). System memory holds the instructions that are
performed by the processor.
Your system memory is organized into eight channels(one memory slot per channel).
Installing and removing system components
105
