Dell PowerEdge XR8620t

Installing and removing system components
Topics:
• Safety instructions
•
Before working inside your system
• After working inside your system
• XR8000r chassis
• Sled cover
• Air shroud
• M.2 direct riser module
• ROR N1 module
• 2U sled
• Storage interposer module
• Cooling fans
• Expansion cards and expansion card risers
• BOSS-N1 card
• Power distribution board
• Cable routing
• System memory
• Processor and heat sink module
• System battery
• System board
• Trusted Platform Module
Safety instructions
CAUTION:
Many repairs may only be done by a certified service technician. You should only perform
troubleshooting and simple repairs as authorized in your product documentation, or as directed by the online or
telephone service and support team. Damage due to servicing that is not authorized by Dell is not covered by
your warranty. Read and follow the safety instructions that are shipped with your product.
NOTE: It is recommended that you always use an antistatic mat and antistatic strap while working on components inside
the system.
NOTE: System with a cold start requirement will require active heating. When the temperature is below 5°C, it will
continue to heat up to below 10°C and stop heating.
Before working inside your system
Prerequisites
Follow the safety guidelines listed in the Safety instructions.
Steps
1. Power off the sled.
2. Remove the sled from the enclosure.
